The Zenith Radio Model G500 Electrical Restoration

 Return to Catalog.
vadaxradio097031.gif vadaxradio097030.gif vadaxradio097029.gif vadaxradio097028.gif vadaxradio097027.gif vadaxradio097026.gif
Replacing the Electrolytic Capacitor
Removing the Aluminum can.
Arranging the 4 new electrolytic Capacitors
Connecting the 4 new electrolytic Capacitors
A new cardboard cylinder is used to hold the caps.. The old cylinder was torn during the removal.
Replacing the paper roll capacitors.
Before
HV filter capacitor added
Before
Before
paper roll cap
Before
Re-cap
Re-cap
Re-cap
Silicon Diode replaces the selenium rectifier
old parts
Blown paper roll filter cap
Vadax Radio
All resitors checked within 20%
